Carbon resistors are most popular types of resistors which are widely employed in electrical and electronics projects. Did you know that actual size of resistors depends on the wattage (power ratings). The chart given below displays the watts of resistors and their sizes. Here 1/8 watt, 1/4 watt, 1/2 watt and 1-watt resistors are shown:
